ABM 50 CNC
Tube Bending Machine
ABM 50 CNC Tube Bending Machine bends tubes perfectly up to 50 mm diameter . This powerful machine provides convenience and increases efficiency with its advanced CNC feature.
- Bending, moving ahead, postponing and turning with servo control
- Controlling ability of servo axis speeds from control panel
- Hydraulic assistant axies
- Foot pedal control
- Step by step and full automatic working capability
- Three lines dies operational ability
- Dies can be supplied for any demanded size
- Operational ability with / without mandrel
- Simple or complex shaped bendings for steel, stainless steel, aluminum and similar bendable materials
- Capability of bending steel, stainless steel, aluminum and similar bendable tubes in simple or compex shapes
- Possibility of bending longer tubes than the machine ength. (it’s not for all diameters)
- Unlimited angle obtaining possibility with rolling system
- Spiral bending (only on certain diameters)
- Tube punching system
- Auto-lubrication for mandrel
- Hydraulic oil cooler
- Practical interface program prepared in Akyapak
- Program making possibility in YBC mode
- Tube length can be calculated according top art program
- 3D preview of writen program
- Motors in variable voltage and frequency
- 15" color touchscreen PC
- Starting up serial production after short period training
- Suitable for CE, ISO 9001-2015, TSEK and TURQUM certificates
