| Specification | Details |
|---|---|
| Laser Type/Wavelength | Nd:YAG, 1064 nm |
| Average Power | 200 W |
| Peak Pulse Power | 9 kW |
| Pulse Energy | 90 J |
| Pulse Duration | 0.5–20 ms |
| Pulse Frequency | Single pulse – 100 Hz |
| Operating Mode | Pulsed |
| Welding Spot Ø | 0.2–2.0 mm with micro welding function (optional) < 100 µm |
| Focusing Objective | 150 mm, further ones according to lens data sheet |
| Pulse Shaping | Adjustability of power curve within a laser pulse |
| Display and Operation | 12.1“ Touchscreen-Display |
